1.Applicable models: Jaguar Land Rover with a screen above 10 inches, as shown in the picture below with a green network signal output model;

2.Input: Ethernet

3.Output mode: dual optical fiber/dual coaxial;

4.A player with optical fiber/coaxial output can be connected externally. Signal priority to external audio sources, automatic switching;

5.Output signals to two DSPs, and the front,back, left and right can be independently controlled when two DSPs are added.

6.Keep all original media and alarm sounds and the steering wheel can control the volume level;

Panel description

1.External Audio Optical Input
3.External Audio coaxial Input
4.Models and output mode settings
5.Power supply
6.ACT/Network Activity Indicator
7.REM-OUT Power Indicator
8.NET network interface

9.Front speaker optical fiber output
10.Front speaker coaxial output
11.Rear speaker coaxial output
12.Rear speaker optical fiber output
